TABLE 1
Inductance Percent L Test SRF(MHz) Resistance
L( μH) Tolerance Frequency Min. RDC( Ω)±20% IDC1(A) IDC2(A)
1.0 N 100kHz/0.25V 100 30m 2.10 2.10
1.5 N 100kHz/0.25V 87 40m 1.80 1.82
2.2 M,N 100kHz/0.25V 64 60m 1.48 1.50
3.3 M,N 100kHz/0.25V 49 80m 1.21 1.23
4.3 M,N 100kHz/0.25V 40 0.12 1.02 1.04
4.7 M,N 100kHz/0.25V 40 0.12 1.02 1.04
6.8 M,N 100kHz/0.25V 36 0.16 0.87 0.88
10 M,N 100kHz/0.25V 28 0.23 0.70 0.71
22 M,N 100kHz/0.25V 20 0.52 0.47 0.47
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo：drop 30% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ Typ.)
Rated DC Current： The less value whith is IDC1 or IDC2.
MNR-3015-SERIES Page-2/8
MNR-3015-100□
MNR-3015-6R8□
MNR-3015-3R3□
Rated DC Current
MNR-3015-220□
MAGLAYERS
PT/NO.
MNR-3015-1R0□
MNR-3015-2R2□
MNR-3015-4R7□
MNR-3015-1R5□
MNR-3015-4R3□
