TABLE 1
Inductance Percent L Test SRF(MHz) Resistance
L( μH) Tolerance Frequency Min. RDC( Ω)±20% IDC1(A) IDC2(A)
1.0 N 100KHz/0.25V 110 50m 1.50 1.49
1.5 N 100KHz/0.25V 92 60m 1.36 1.40
2.2 M,N 100KHz/0.25V 70 80m 1.10 1.20
3.3 M,N 100KHz/0.25V 55 0.10 0.91 1.05
4.7 M,N 100KHz/0.25V 48 0.13 0.77 0.98
6.8 M,N 100KHz/0.25V 40 0.19 0.60 0.74
10 M,N 100KHz/0.25V 32 0.29 0.54 0.63
15 M,N 100KHz/0.25V 27 0.45 0.44 0.485
33 M,N 100KHz/0.25V 19 1.03 0.31 0.33
47 M,N 100KHz/0.25V 17 1.45 0.25 0.28
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： drop 30% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ Typ.)
Rated DC Current： The less value whith is IDC1 or IDC2.
MNR-3012-SERIES Page-2/8
Rated DC Current
MNR-3012-1R5□
MNR-3012-2R2□
MNR-3012-3R3□
MAGLAYERS
PT/NO.
MNR-3012-1R0□
MNR-3012-330□
MNR-3012-470□
MNR-3012-4R7□
MNR-3012-100□
MNR-3012-150□
MNR-3012-6R8□
M A G .L A Y E R S
