TABLE 1
Inductance Percent Test Resistance
L( μH) Tolerance Frequency RDC( Ω)±20% IDC1(A) IDC2(A)
2.0 N 100kHz/0.5V 11.7m 10 6.2 2R0
4.7 N 100kHz/0.5V 15.0m 7.3 5.5 4R2
7.0 N 100kHz/0.5V 17.7m 5.7 5.0 7R0
10 M,N 100kHz/0.5V 20.2m 5.0 4.8 100
15 M,N 100kHz/0.5V 23.7m 4.2 4.4 150
22 M,N 100kHz/0.5V 31.6m 3.5 3.8 220
33 M,N 100kHz/0.5V 40.6m 2.8 3.4 330
47 M,N 100kHz/0.5V 57.8m 2.4 2.8 470
68 M,N 100kHz/0.5V 78.7m 2.0 2.4 680
100 M,N 100kHz/0.5V 0.123 1.6 1.9 101
220 M,N 100kHz/0.5V 0.273 1.0 1.2 221
1000 M 100kHz/0.5V 1.10 0.3 0.35 102
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 10%)@ ambient temp. 25℃
IDC2： Based on temperature rise (△T：40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCD Page-2/8
MSCDRI-126F-100□
MSCDRI-126F-680□
MSCDRI-126F-150□
MSCDRI-126F-220□
MSCDRI-126F-330□
MSCDRI-126F-470□
MSCDRI-126F-102□
MSCDRI-126F-101□
MSCDRI-126F-221□
Marking
MAGLAYERS
PT/NO.
Rated DC Current
MSCDRI-126F-2R0□
MSCDRI-126F-4R2□
MSCDRI-126F-7R0□
