TABLE 1
Inductance Percent Test Resistance
L( μH) Tolerance Frequency RDC( Ω)±20% IDC1(A) IDC2(A)
3.3 N 100kHz,0.25V 16.1m 4.90 3.70 3R3
5.6 N 100kHz,0.25V 22.0m 3.80 3.20 5R6
10 M,N 100kHz,0.25V 36.4m 3.00 2.50 100
15 M,N 100kHz,0.25V 47.2m 2.40 2.20 150
22 M,N 100kHz,0.25V 59.1m 2.10 1.90 220
33 M,N 100kHz,0.25V 81.5m 1.60 1.70 330
47 M,N 100kHz,0.25V 0.10 1.40 1.50 470
68 M,N 100kHz,0.25V 0.14 1.20 1.30 680
100 M,N 100kHz,0.25V 0.20 1.00 1.10 101
150 M,N 100kHz,0.25V 0.35 0.79 0.81 151
220 M,N 100kHz,0.25V 0.47 0.65 0.70 221
330 M,N 100kHz,0.25V 0.68 0.54 0.58 331
470 M,N 100kHz,0.25V 1.03 0.47 0.47 471
680 M,N 100kHz,0.25V 1.60 0.38 0.38 681
1000 M,N 100kHz,0.25V 2.80 0.32 0.29 102
1500 M,N 100kHz,0.25V 3.40 0.22 0.26 152
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦－10%)
IDC2： Based on temperature rise (△T：40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDRI-105F-SERIES Page-2/8
MSCDRI-105F-151□
Marking
MAGLAYERS
PT/NO.
Rated DC Current
MSCDRI-105F-221□
MSCDRI-105F-3R3□
MSCDRI-105F-5R6□
MSCDRI-105F-100□
MSCDRI-105F-150□
MSCDRI-105F-220□
MSCDRI-105F-330□
MSCDRI-105F-470□
MSCDRI-105F-680□
MSCDRI-105F-101□
MSCDRI-105F-152□
MSCDRI-105F-331□
MSCDRI-105F-471□
MSCDRI-105F-681□
MSCDRI-105F-102□
MAG.LAYERS
