TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
1.1 M,N 100kHz/025V 20m 3.87 4.07 1R1
2.0 N 100kHz/025V 27m 2.92 3.30 2R0
3.3 M,N 100kHz/025V 34m 2.36 2.83 3R3
4.7 M,N 100kHz/025V 45m 1.87 2.51 4R7
6.8 N 100kHz/025V 68m 1.51 2.06 6R8
10 M,N 100kHz/025V 90m 1.33 1.76 100
15 M,N 100kHz/025V 0.142 1.05 1.37 150
22 M,N 100kHz/025V 0.208 0.86 1.01 220
33 M,N 100kHz/025V 0.257 0.72 0.94 330
47 M,N 100kHz/025V 0.352 0.62 0.80 470
68 M,N 100kHz/025V 0.525 0.51 0.65 680
100 M,N 100kHz/025V 0.801 0.43 0.55 101
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ ※ IDC1： Based on inductance change (△L/Lo： ≦ drop 30%) @ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
Page-2/8
MSCDRI-5030F-3R3□
MSCDRI-5030F-680□
MSCDRI-5030F-4R7□
MSCDRI-5030F-6R8□
MSCDRI-5030F-100□
MSCDRI-5030F-470□
MSCDRI-5030F-SERIES
MSCDRI-5030F-101□
Marking
MAGLAYERS
PT/NO.
MSCDRI-5030F-330□
MSCDRI-5030F-1R1□
MSCDRI-5030F-150□
MSCDRI-5030F-220□
MSCDRI-5030F-2R0□
