TABLE 1
Inductance Percent Test Resistance
L( μH) Tolerance Frequency RDC( Ω) Max. IDC1(A) IDC2(A)
2.0 N 100kHz/0.25V 19m 3.00 4.14 2R0
2.7 N 100kHz/0.25V 22m 2.69 3.91 2R7
3.3 M,N 100kHz/0.25V 26m 2.57 3.52 3R3
4.7 M,N 100kHz/0.25V 32m 2.08 3.15 4R7
6.2 N 100kHz/0.25V 35m 1.84 3.02 6R2
8.2 N 100kHz/0.25V 44m 1.54 2.64 8R2
10 M,N 100kHz/0.25V 50m 1.49 2.46 100
12 M,N 100kHz/0.25V 62m 1.28 2.17 120
15 M,N 100kHz/0.25V 77m 1.10 1.93 150
18 M,N 100kHz/0.25V 82m 1.05 1.90 180
22 M,N 100kHz/0.25V 0.106 0.97 1.62 220
27 M,N 100kHz/0.25V 0.140 0.82 1.39 270
33 M,N 100kHz/0.25V 0.162 0.76 1.28 330
39 M,N 100kHz/0.25V 0.191 0.70 1.20 390
47 M,N 100kHz/0.25V 0.208 0.68 1.12 470
56 M,N 100kHz/0.25V 0.257 0.60 1.00 560
68 M,N 100kHz/0.25V 0.319 0.56 0.89 680
82 M,N 100kHz/0.25V 0.420 0.47 0.76 820
100 M,N 100kHz/0.25V 0.477 0.45 0.71 101
※ □ specify the inductance tolerance,M(±20%),N( ±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 30%)@ ambient temp. 25℃
IDC2： Based on temperature rise (△T：40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDRI-6035L-SERIES Page-2/8
