TABLE 1
Inductance Percent Test Resistance
L( μH) Tolerance Frequency RDC( Ω) Max. IDC1(A) IDC2(A)
1.0 N 100kHz/0.25V 17m 3.50 4.35 1R0
1.5 N 100kHz/0.25V 21m 2.94 3.74 1R5
2.0 M,N 100kHz/0.25V 29m 2.47 2.91 2R0
2.2 N 100kHz/0.25V 29m 2.47 2.91 2R2
3.3 N 100kHz/0.25V 47m 1.99 2.47 3R3
4.7 N 100kHz/0.25V 66m 1.59 1.93 4R7
6.2 N 100kHz/0.25V 74m 1.49 1.81 6R2
8.2 N 100kHz/0.25V 0.102 1.25 1.54 8R2
10 M,N 100kHz/0.25V 0.118 1.22 1.36 100
12 M,N 100kHz/0.25V 0.154 0.99 1.38 120
15 M,N 100kHz/0.25V 0.179 0.94 1.03 150
18 M,N 100kHz/0.25V 0.207 0.83 1.12 180
22 M,N 100kHz/0.25V 0.253 0.80 0.92 220
27 M,N 100kHz/0.25V 0.331 0.65 0.81 270
33 M,N 100kHz/0.25V 0.368 0.63 0.76 330
39 M,N 100kHz/0.25V 0.473 0.55 0.70 390
47 M,N 100kHz/0.25V 0.542 0.50 0.65 470
※ □ specify the inductance tolerance,M(±20%),N( ±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 30%) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T：40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
