TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω) Max.
1.0 N 100kHz/0.25V 16m 1R0
1.5 M,N 100kHz/0.25V 21m 1R5
2.0 N 100kHz/0.25V 28m 2R0
3.3 N 100kHz/0.25V 47m 3R3
4.7 M,N 100kHz/0.25V 65m 4R7
6.8 N 100kHz/0.25V 98m 6R8
8.2 N 100kHz/0.25V 0.102 8R2
10 M,N 100kHz/0.25V 0.118 100
12 M,N 100kHz/0.25V 0.153 120
15 M,N 100kHz/0.25V 0.179 150
18 M,N 100kHz/0.25V 0.207 180
22 M,N 100kHz/0.25V 0.253 220
27 M,N 100kHz/0.25V 0.330 270
33 M,N 100kHz/0.25V 0.368 330
39 M,N 100kHz/0.25V 0.473 390
47 M,N 100kHz/0.25V 0.542 470
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※IDC : Based on inductance change (△L/Lo： drop 30 max) @ ambient temperature 25℃and
Based on temperature rise (△T： 40℃ TYP.)
Page-2/8 MSCDRI-6020B-SERIES
MSCDRI-6020B-1R0□ 3.50
Marking
MAGLAYERS
PT/NO. IDC(A)
MSCDRI-6020B-1R5□ 2.94
MSCDRI-6020B-2R0□ 2.47
MSCDRI-6020B-3R3□ 1.99
MSCDRI-6020B-100□ 1.22
MSCDRI-6020B-4R7□ 1.59
MSCDRI-6020B-6R8□ 1.37
MSCDRI-6020B-8R2□ 1.25
MSCDRI-6020B-120□ 0.99
MSCDRI-6020B-150□ 0.94
MSCDRI-6020B-180□ 0.83
MSCDRI-6020B-220□ 0.80
MSCDRI-6020B-270□ 0.65
MSCDRI-6020B-330□ 0.63
MSCDRI-6020B-390□ 0.55
MSCDRI-6020B-470□ 0.50
