TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω) Max.
10 M,N 100kHz,0.25V 70m 100
12 M,N 100kHz,0.25V 70m 120
15 M,N 100kHz,0.25V 80m 150
18 M,N 100kHz,0.25V 0.10 180
22 M,N 100kHz,0.25V 0.12 220
27 M,N 100kHz,0.25V 0.16 270
33 M,N 100kHz,0.25V 0.18 330
39 M,N 100kHz,0.25V 0.18 390
47 M,N 100kHz,0.25V 0.27 470
56 M,N 100kHz,0.25V 0.29 560
68 M,N 100kHz,0.25V 0.33 680
82 M,N 100kHz,0.25V 0.43 820
100 M,N 100kHz,0.25V 0.49 101
120 M,N 100kHz,0.25V 0.68 121
150 M,N 100kHz,0.25V 0.94 151
180 M,N 100kHz,0.25V 1.00 181
220 M,N 100kHz,0.25V 1.18 221
270 M,N 100kHz,0.25V 1.30 271
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※IDC : Based on inductance change (△L/Lo： drop 10% max) and
Based on temperature rise (△T： 40℃ TYP.)
MSCDRI-74B-SERIES Page-2/8
MSCDRI-74B-100□
Marking
MAGLAYERS
PT/NO. IDC(A)
1.50
MSCDRI-74B-120□ 1.30
MSCDRI-74B-150□ 1.22
MSCDRI-74B-180□ 1.13
MSCDRI-74B-220□ 1.08
MSCDRI-74B-270□ 0.84
MSCDRI-74B-330□ 0.78
MSCDRI-74B-390□ 0.74
MSCDRI-74B-470□ 0.66
MSCDRI-74B-271□ 0.28
MSCDRI-74B-560□ 0.64
MSCDRI-74B-680□ 0.54
MSCDRI-74B-181□ 0.33
MSCDRI-74B-221□ 0.32
MSCDRI-74B-121□ 0.40
MSCDRI-74B-151□ 0.35
MSCDRI-74B-820□ 0.52
MSCDRI-74B-101□ 0.42
