TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
1.2 N 100kHz/0.25V 33m 1.5 3.00 1R2
3.3 N 100kHz/0.25V 66m 0.80 2.00 3R3
3.9 N 100kHz/0.25V 81m 0.75 1.75 3R9
4.7 N 100kHz/0.25V 91m 0.68 1.72 4R7
5.6 N 100kHz/0.25V 0.102 0.62 1.64 5R6
6.8 N 100kHz/0.25V 0.130 0.58 1.30 6R8
8.2 N 100kHz/0.25V 0.140 0.51 1.28 8R2
10 M,N 100kHz/0.25V 0.190 0.46 1.07 100
12 M,N 100kHz/0.25V 0.205 0.42 0.98 120
15 M,N 100kHz/0.25V 0.272 0.38 0.87 150
18 M,N 100kHz/0.25V 0.327 0.34 0.76 180
22 M,N 100kHz/0.25V 0.356 0.31 0.66 220
27 M,N 100kHz/0.25V 0.470 0.28 0.60 270
33 M,N 100kHz/0.25V 0.560 0.26 0.55 330
39 M,N 100kHz/0.25V 0.700 0.24 0.47 390
47 M,N 100kHz/0.25V 0.775 0.21 0.45 470
560 M,N 100kHz/0.25V 13.0 0.07 0.13 561
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 35%) @ ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDRI-3D16LD-SERIES Page-2/8
Marking
MAGLAYERS
PT/NO.
MSCDRI-3D16LD-3R3□
MSCDRI-3D16LD-1R2□
MSCDRI-3D16LD-3R9□
MSCDRI-3D16LD-4R7□
MSCDRI-3D16LD-330□
MSCDRI-3D16LD-390□
MSCDRI-3D16LD-220□
MSCDRI-3D16LD-270□
MSCDRI-3D16LD-100□
MSCDRI-3D16LD-120□
MSCDRI-3D16LD-150□
MSCDRI-3D16LD-180□
MSCDRI-3D16LD-561□
MSCDRI-3D16LD-470□
MSCDRI-3D16LD-5R6□
MSCDRI-3D16LD-6R8□
MSCDRI-3D16LD-8R2□
