TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
1.5 Y,N 100kHz/0.25V 76m 2.60 1.85 1R5
2.2 N 100kHz/0.25V 0.129 2.00 1.32 2R2
2.4 N 100kHz/0.25V 0.129 2.00 1.32 2R4
3.2 N 100kHz/0.25V 0.139 1.80 1.25 3R2
4.7 M,Y,N 100kHz/0.25V 0.214 1.45 1.04 4R7
6.8 M,Y,N 100kHz/0.25V 0.29 1.20 0.84 6R8
10 M,Y,N 100kHz/0.25V 0.44 1.00 0.67 100
15 M,N 100kHz/0.25V 0.65 0.80 0.50 150
18 M,N 100kHz/0.25V 0.74 0.73 0.49 180
22 M,Y,N 100kHz/0.25V 0.83 0.65 0.48 220
※ □ specify the inductance tolerance,M( ±20%),Y(±25%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 35%) @ ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDRI-3D14HP-SERIES Page-2/8
MSCDRI-3D14HP-220□
MSCDRI-3D14HP-3R2□
MSCDRI-3D14HP-4R7□
MSCDRI-3D14HP-6R8□
MSCDRI-3D14HP-100□
MSCDRI-3D14HP-180□
MSCDRI-3D14HP-150□
Marking
MAGLAYERS
PT/NO.
MSCDRI-3D14HP-2R4□
MSCDRI-3D14HP-1R5□
MSCDRI-3D14HP-2R2□
MAG.LAYERS
