TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC(A)
0.18 N 100kHz/0.25V 5.0m 9.0 R18
0.33 N 100kHz/0.25V 9.0m 7.0 R33
0.47 M,N 100kHz/0.25V 10.0m 6.0 R47
0.56 M,N 100kHz/0.25V 13.8m 5.2 R56
1.0 M 100kHz/0.25V 18.0m 4.4 1R0
1.2 M 100kHz/0.25V 19.0m 4.3 1R2
1.5 M 100kHz/0.25V 20.0m 4.2 1R5
2.2 M 100kHz/0.25V 35.0m 3.1 2R2
3.3 M 100kHz/0.25V 43.0m 2.9 3R3
4.7 M 100kHz/0.25V 54.0m 2.2 4R7
6.8 M 100kHz/0.25V 90.0m 1.7 6R8
10 M 100kHz/0.25V 0.111 1.5 100
15 M 100kHz/0.25V 0.175 1.2 150
22 M 100kHz/0.25V 0.255 1.0 220
33 M 100kHz/0.25V 0.370 0.82 330
47 M 100kHz/0.25V 0.474 0.72 470
68 M 100kHz/0.25V 0.750 0.58 680
100 M 100kHz/0.25V 1.110 0.47 101
※ □ specify the inductance tolerance , M( ±20%) , N(±30%)
※IDC : Based on inductance change (△L/Lo：drop 10% Max.) @ ambient temp. 25℃ and
Based on temperature rise (△T： 40℃ TYP.)
MSCDB-0905H-SERIES Page-2/8
MSCDB-0905H-100□
MSCDB-0905H-1R2□
MSCDB-0905H-150□
MSCDB-0905H-101□
MSCDB-0905H-220□
MSCDB-0905H-330□
MSCDB-0905H-470□
MSCDB-0905H-680□
MSCDB-0905H-3R3□
MSCDB-0905H-R47□
Marking
MAGLAYERS
PT/NO.
MSCDB-0905H-R18□
MSCDB-0905H-R33□
MSCDB-0905H-4R7□
MSCDB-0905H-6R8□
MSCDB-0905H-R56□
MSCDB-0905H-1R0□
MSCDB-0905H-1R5□
MSCDB-0905H-2R2□
