TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
2.2 M,N 100kHz/0.25V 30m 3.8 4.4 2R2
4.7 N 100kHz/0.25V 60m 2.7 3.2 4R7
6.8 M,N 100kHz/0.25V 75m 2.6 3.0 6R8
10 M,N 100kHz/0.25V 90m 2.4 2.3 100
15 M,N 100kHz/0.25V 0.12 2.0 1.9 150
22 M,N 100kHz/0.25V 0.19 1.6 1.5 220
33 M,N 100kHz/0.25V 0.25 1.4 1.2 330
47 M,N 100kHz/0.25V 0.32 1.0 1.0 470
68 M,N 100kHz/0.25V 0.55 0.9 0.9 680
100 K,M 100kHz/0.25V 0.70 0.7 0.73 101
150 K,M 100kHz/0.25V 1.00 0.6 0.62 151
220 K,M 100kHz/0.25V 1.60 0.5 0.51 221
330 K,M 100kHz/0.25V 2.20 0.4 0.40 331
470 K,M 100kHz/0.25V 3.30 0.3 0.33 471
680 K,M 100kHz/0.25V 4.40 0.2 0.28 681
1000 K,M 100kHz/0.25V 7.00 0.1 0.23 102
※ □ specify the inductance tolerance,K( ±10%),M(±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦drop 10%)@ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
Page 2/8 MSCDB-1303-SERIES
MSCDB-1303-101□
MSCDB-1303-151□
MSCDB-1303-221□
MSCDB-1303-331□
MSCDB-1303-471□
MSCDB-1303-681□
MSCDB-1303-102□
Marking
MAGLAYERS
PT/NO.
MSCDB-1303-220□
MSCDB-1303-2R2□
MSCDB-1303-4R7□
MSCDB-1303-100□
MSCDB-1303-6R8□
MSCDB-1303-470□
MSCDB-1303-680□
MSCDB-1303-330□
MSCDB-1303-150□
MAG.LAYERS
