TABLE 1
Inductance Percent Test Resistance
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
1.0 M,N 100kHz/0.25V 62m 1.60 2.05 1R0
2.2 M,N 100kHz/0.25V 0.13 1.20 1.50 2R2
3.3 M,N 100kHz/0.25V 0.14 0.90 1.30 3R3
4.7 M,N 100kHz/0.25V 0.18 0.65 1.05 4R7
5.6 M,N 100kHz/0.25V 0.26 0.60 1.00 5R6
6.8 M,N 100kHz/0.25V 0.27 0.55 0.90 6R8
8.2 M,N 100kHz/0.25V 0.36 0.50 0.81 8R2
10 M,N 100kHz/0.25V 0.39 0.45 0.70 100
12 M,N 100kHz/0.25V 0.45 0.42 0.65 120
15 M,N 100kHz/0.25V 0.75 0.30 0.63 150
18 M,N 100kHz/0.25V 0.76 0.29 0.60 180
22 M,N 100kHz/0.25V 0.92 0.25 0.57 220
27 M,N 100kHz/0.25V 1.12 0.23 0.50 270
33 M,N 100kHz/0.25V 1.43 0.20 0.45 330
47 M,N 100kHz/0.25V 1.69 0.17 0.35 470
56 M,N 100kHz/0.25V 1.92 0.15 0.32 560
68 M,N 100kHz/0.25V 2.86 0.13 0.28 680
82 M,N 100kHz/0.25V 3.25 0.128 0.27 820
100 K,M 100kHz/0.25V 4.55 0.125 0.26 101
120 K,M 100kHz/0.25V 4.55 0.123 0.25 121
180 K,M 100kHz/0.25V 7.15 0.122 0.22 181
220 K,M 100kHz/0.25V 8.32 0.120 0.20 221
270 K,M 100kHz/0.25V 12.61 0.115 0.18 271
330 K,M 100kHz/0.25V 14.56 0.10 0.16 331
390 K,M 100kHz/0.25V 16.12 0.09 0.12 391
470 K,M 100kHz/0.25V 18.20 0.09 0.10 471
※ □ specify the inductance tolerance, K( ±10%), M(±20%), N(±30%)
※ IDC1： Based on inductance change (△L/Lo： drop 10% Max.) @ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCD-0315-SERIES Page-2/8
Marking
MSCD-0315-391□
MSCD-0315-471□
MSCD-0315-271□
MSCD-0315-331□
MSCD-0315-181□
MSCD-0315-221□
MSCD-0315-120□
MSCD-0315-470□
MSCD-0315-220□
MSCD-0315-121□
MSCD-0315-8R2□
MSCD-0315-100□
MSCD-0315-101□
MSCD-0315-270□
MSCD-0315-180□
MSCD-0315-330□
MSCD-0315-560□
MSCD-0315-820□
MSCD-0315-680□
Rated DC Current MAGLAYERS
PT/NO.
MSCD-0315-150□
MSCD-0315-2R2□
MSCD-0315-1R0□
MSCD-0315-5R6□
MSCD-0315-6R8□
MSCD-0315-4R7□
MSCD-0315-3R3□
