TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
4.7 M 100kHz/0.25V 15.0m 9.0 6.40
10 K,M 100kHz/0.25V 21.0m 7.0 5.50
15 K,M 100kHz/0.25V 31.2m 5.0 4.20
22 K,M 100kHz/0.25V 44.1m 4.5 3.80
33 K,M 100kHz/0.25V 66.5m 3.5 3.10
100 J,K 100KHz/0.25V 0.15 2.2 2.00
150 K,M 100KHz/0.25V 0.21 1.9 1.80
470 K,M 100KHz/0.25V 0.70 1.0 0.80
680 K,M 100KHz/0.25V 0.96 0.8 0.70
820 K,M 100KHz/0.25V 1.20 0.75 0.65
1000 J,K,M 100KHz/0.25V 1.50 0.65 0.60
※ □ specify the inductance tolerance,J( ±5%),K(±10%),M(±20%)
※ IDC1：Based on inductance change (△L/Lo：drop 10% Max.) @ambient temperature 25℃
IDC2：Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
Page-2/4
MCD-1012-100□
MCD-1012-SERIES
MAGLAYERS
PT/NO.
MCD-1012-102□
MCD-1012-150□
MCD-1012-220□
MCD-1012-330□
MCD-1012-151□
MCD-1012-4R7□
MCD-1012-681□
MCD-1012-101□
MCD-1012-471□
MCD-1012-821□
