TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max.
10 M 100kHz/0.25V 22m
12 M 100kHz/0.25V 23m
15 M 100kHz/0.25V 26m
18 M 100kHz/0.25V 33m
22 K,M 100kHz/0.25V 37m
27 M 100kHz/0.25V 48m
33 K,M 100kHz/0.25V 55m
39 K,M 100kHz/0.25V 73m
47 K,M 100kHz/0.25V 83m
56 K,M 100kHz/0.25V 92m
68 K,M 100kHz/0.25V 0.12
82 K,M 100kHz/0.25V 0.14
100 K,M 100kHz/0.25V 0.16
120 K,M 100kHz/0.25V 0.20
150 K,M 100kHz/0.25V 0.23
180 K,M 100kHz/0.25V 0.31
220 K,M 100kHz/0.25V 0.34
270 K,M 100kHz/0.25V 0.40
330 K,M 100kHz/0.25V 0.52
390 K,M 100kHz/0.25V 0.65
470 K,M 100kHz/0.25V 0.71
560 K,M 100kHz/0.25V 1.00
680 K,M 100kHz/0.25V 1.10
820 K,M 100kHz/0.25V 1.30
1000 K,M 100kHz/0.25V 1.70
※ 1. □ Specify the inductance tolerance, K( ±10%), M(±20%)
※ 2. IDC : Based on inductance change (△L/Lo：drop 10% Max.) @ ambient temp. 25℃ and
Based on temperature rise (△T： 40℃ TYP.)
MCD-110C-SERIES Page-2/4
