TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
10 M 100kHz/0.25V 40m 2.6 4.10
15 M 100kHz/0.25V 50m 2.1 3.80
22 M 100kHz/0.25V 60m 1.7 3.30
47 K,M 100kHz/0.25V 0.10 1.3 2.20
56 K,M 100kHz/0.25V 0.11 1.2 2.00
220 K,M 100kHz/0.25V 0.38 0.64 1.10
470 K,M 100kHz/0.25V 0.89 0.43 0.70
560 K,M 100kHz/0.25V 1.01 0.40 0.63
1000 K,M 100kHz/0.25V 1.84 0.30 0.50
1500 K,M 10kHz/0.25V 2.80 0.23 0.42
2200 K,M 10kHz/0.25V 4.21 0.19 0.30
3300 K,M 10kHz/0.25V 6.16 0.15 0.25
10000 K,M 10kHz/0.25V 22.0 89m 0.14
47000 K,M 10kHz/0.25V 96.4 38m 70m
※ 1. □ Specify the inductance tolerance, K( ±10%), M(±20%)
※ IDC1： Based on inductance change (△L/Lo：drop 10% Max.)@ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
Page-2/4
MCD-895C-470
MCD-895C-560
MCD-895C-471
MCD-895C-SERIES
MCD-895C-332
MCD-895C-220
MAGLAYERS
PT/NO.
MCD-895C-150
MCD-895C-100
MCD-895C-222
MCD-895C-473
MCD-895C-561
MCD-895C-221
MCD-895C-103
MCD-895C-102
MCD-895C-152
M AG.LAYERS
