TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
100 K,M 100kHz/0.25V 0.43 0.56 0.85
220 K,M 100kHz/0.25V 0.96 0.40 0.55
※ □ specify the inductance tolerance,K( ±10%),M(±20%)
※ IDC1： Based on inductance change (△L/Lo：drop 10% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
Page-3/5 Page-2/4
MAGLAYERS
PT/NO.
MCD-664C-221□
MCD-664C-101□
MCD-664C-SERIES
