TYPICAL ELECTRICAL CHARACTERISTICS
INDUCTANCE vs. DC CURRENT@100kHz/1.0V
Ambient Temperature : 25℃
ATTACHMENT-1
MSI-600608-SERIES-□
MAG.LAYERS
0
30
60
90
120
0 10 20 30 40 50 60
Ind
u
cta
n
ce
(n
H)
DC Current(A)
MSI-600608-R10□-E
0.00
0.05
0.10
0.15
0.20
0.25
0.30
0 3 6 9 12 15 18 21 24
In
d
u
c
ta
n
c
e
(u
H)
DC Current(A)
MSI-600608-R20□-E
