(5) LAND DIMENSION (Ref.)
PCB: GLASS EPOXY t＝1.6mm
(5)-1 LAND PATTERN DIMENSIONS
(STANDARD PATTERN)
Unit: mm
(5)-2 FLOW SOLDERING
SMB-853025 Page-5/7
MAG.LAYERS
3 0 0
1 0 0
1 5 0
2 0 0
2 6 0
T e m p e r a t u r e ( ℃ )
5 0
P r e h e a t i n g
N a t u r a l C o o li n g
T i m e
1 0 s e c 1 t o 4 m in . m o r e t h a n 2 m i n .
S o ld in g
2 6 0 ℃
