TABLE 1
Inductance Percent L Freq. Quality Q Freq. SRF DCR IDC
L(nH) Tolerance (MHz) Min. (MHz) (MHz)Min. ( Ω) Max. (mA) Max.
MHSC-2012C-2N2□ 2.2 K 250 50 1000 7900 0.05 800
MHSC-2012C-2N7□ 2.7 J,K 250 50 1500 7900 0.058 800
MHSC-2012C-2N8□ 2.8 J,K 250 55 1500 7900 0.06 800
MHSC-2012C-3N0□ 3.0 J,K 250 55 1500 7900 0.08 800
MHSC-2012C-3N3□ 3.3 J,K 250 45 1500 7900 0.12 600
MHSC-2012C-5N1□ 5.1 J,K 250 60 1000 5800 0.06 600
MHSC-2012C-5N6□ 5.6 J,K 250 65 1000 5500 0.08 600
MHSC-2012C-6N2□ 6.2 J,K 250 50 1000 5500 0.11 800
MHSC-2012C-6N8□ 6.8 J,K 250 50 1000 5500 0.11 600
MHSC-2012C-7N5□ 7.5 J,K 250 50 1000 4500 0.14 600
MHSC-2012C-8N2□ 8.2 J,K 250 50 1000 4700 0.16 600
MHSC-2012C-8N7□ 8.7 J,K 250 50 1000 4700 0.23 600
MHSC-2012C-10N□ 10 G,J,K 250 60 500 4200 0.10 600
MHSC-2012C-12N□ 12 G,J,K 250 50 500 4000 0.15 600
MHSC-2012C-14N□ 14 G,J,K 250 50 500 3400 0.17 600
MHSC-2012C-15N□ 15 G,J,K 250 50 500 3400 0.17 700
MHSC-2012C-16N□ 16 G,J,K 250 50 500 3300 0.19 600
MHSC-2012C-18N□ 18 G,J,K 250 50 500 3300 0.20 600
MHSC-2012C-22N□ 22 G,J,K 250 55 500 2600 0.22 500
MHSC-2012C-24N□ 24 G,J,K 250 50 500 2000 0.22 500
MHSC-2012C-27N□ 27 G,J,K 250 55 500 2500 0.25 500
MHSC-2012C-33N□ 33 G,J,K 250 60 500 2050 0.27 500
MHSC-2012C-36N□ 36 G,J,K 250 55 500 1700 0.27 500
MHSC-2012C-39N□ 39 G,J,K 250 60 500 2000 0.29 500
MHSC-2012C-43N□ 43 G,J,K 200 60 500 1650 0.34 500
MHSC-2012C-47N□ 47 G,J,K 200 60 500 1650 0.31 700
MHSC-2012C-56N□ 56 G,J,K 200 60 500 1550 0.34 500
MHSC-2012C-68N□ 68 G,J,K 200 60 500 1450 0.38 500
MHSC-2012C-75N□ 75 G,J,K 200 60 500 1400 0.40 400
MHSC-2012C-82N□ 82 G,J,K 150 65 500 1300 0.42 400
MHSC-2012C-91N□ 91 G,J,K 150 65 500 1200 0.48 400
MHSC-2012C-R10□ 100 G,J,K 150 65 500 1200 0.46 400
MHSC-2012C-R11□ 110 G,J,K 150 50 250 1000 0.48 400
MHSC-2012C-R12□ 120 G,J,K 150 50 250 1100 0.51 400
MHSC-2012C-R15□ 150 G,J,K 100 50 250 920 0.56 400
MHSC-2012C-R16□ 160 G,J,K 100 50 250 900 0.60 400
MHSC-2012C-R18□ 180 G,J,K 100 50 250 870 0.64 400
MHSC-2012C-R20□ 200 G,J,K 100 50 250 865 0.68 400
MHSC-2012C-R22□ 220 G,J,K 100 50 250 850 0.70 400
MHSC-2012C-R24□ 240 G,J,K 100 44 250 690 1.00 350
MHSC-2012C-R25□ 250 G,J,K 100 48 250 680 1.00 350
MHSC-2012C-R27□ 270 G,J,K 100 48 250 650 1.00 350
MHSC-2012C-R33□ 330 G,J,K 100 48 250 750 1.40 310
MHSC-2012C-R36□ 360 G,J,K 100 48 250 650 1.45 300
MHSC-2012C-R39□ 390 G,J,K 100 48 250 560 1.50 290
MHSC-2012C-R43□ 430 G,J,K 50 33 100 430 1.70 290
MHSC-2012C-R47□ 470 G,J,K 50 30 100 375 1.76 250
MHSC-2012C-R56□ 560 G,J,K 25 23 50 340 1.90 230
MHSC-2012C-R62□ 620 G,J,K 25 23 50 220 2.20 210
MHSC-2012C-R68□ 680 G,J,K 25 23 50 188 2.20 190
MHSC-2012C-R75□ 750 G,J,K 25 23 50 200 2.30 180
MHSC-2012C-R82□ 820 G,J,K 25 23 50 215 2.35 180
MHSC-2012C-R91□ 910 J,K 25 22 50 210 2.40 180
MHSC-2012C-1R0□ 1000 G,J,K 25 22 50 200 2.45 180
MHSC-2012C-1R2□ 1200 G,J,K 7.9 16 7.9 160 2.45 170
MHSC-2012C-1R5□ 1500 G,J,K 7.9 16 7.9 120 2.50 170
MHSC-2012C-1R8□ 1800 G,J,K 7.9 16 7.9 80 2.50 170
MHSC-2012C-2R2□ 2200 G,J,K 7.9 16 7.9 60 2.70 160
MHSC-2012C-2R7□ 2700 G,J,K 7.9 16 7.9 50 3.80 160
※ 1. Please specify the inductance tolerance, G( ±2%),J(±5%),K(±10%)
2. IDC for a 15 °C rise above 25°C ambient.
