TABLE 1
Rated Insulation
Current Resistance
Min. Typ. (A) Max. (M Ω) Min.
80 230 100MHz/0.5V 2.0m 10.0 10 125
500 700 100MHz/0.5V 6.0m 8.0 10 125
750 1000 100MHz/0.5V 14 m 6.0 10 125
2200 2500 10MHz/0.5V 35 m 1.8 10 125
2300 2700 10MHz/0.5V 50 m 1.5 10 125
Page 2/9
Rated
Voltage
(V)Max. MAGLAYERS PT/NO.
Impedance( Ω)
Test
Frequency
Resistance RDC( Ω)
Max.(1 line)
MCM-1211M-102
MCM-1211M-800
MCM-1211M-SERIES
MCM-1211M-272
MCM-1211M-701
MCM-1211M-222
