TABLE
0.252 ±8% 20 55 33 R20
0.252 ±8% 20 55 33 R24
Test Frequency : 100KHz/0.1V
※ IDC1： Based on inductance change (△L/Lo：drop 20% Typ.) @ ambient temp. 25℃
IDC2：Based on inductance change (△L/Lo： drop 20% Typ.) @ ambient temp. 25℃
IDC3： Based on temperature rise (△T： 40℃ TYP.)
RDC TEST POINT
SCHEMATIC
Page 2/8
L(1-2),L(4-3)
0.24 ±20%
2Lk (nH)
(1-4@2-3 short)
100 ±20%
Marking
MSI-101004PF-R24M-E
IDC1(A )
(1-2,4-3)
Inductance ( μH)
MAGLAYERS
Coupling
Inductance
IDC2(A)
(1-4)@2-3
short
IDC3(A)
(1-4)@2-3
short
Rated DC Current (Max.)
Resistance
RDC(m Ω)
(1-2,4-3)
MSI-101004PF-R20M-E 0.20 ±20% 100 ±20%
MSI-101004PF-SERIES- □
M A G .L A Y E R S
