Low Temperature
Cofired Ceramics Series
CUTTUNG-EDGE TECHNOLOGY OF RF SOLUTION
MAG.LAYERS
4
Part No.
型号
Port
埠
Pass Band
带宽
(MHz)
Insertion
Loss
插入损耗
VSWR
电压
驻波比
Attenuation
带外抑制
Figure
外观
Common to
Low Freq. Port
2400~2500 0.8dB max. 2.0 max. 20dB min. at 4900~6000 MHz
Common to
High Freq. Port
4900~5850 1.1dB max. 2.0 max.
20dB min. at 2400~2500 MHz
15dB min. at 9800~11700 MHz
2400~2500 2.0 max.
LTD-1608-
2G4S1-A2
Common Port
4900~5850
-
2.0 max.
-
C
Common to
Low Freq. Port
2400~2500 0.7dB max. 2.0 max. 20dB min. at 4800~6000 MHz
Common to
High Freq. Port
4900~5850
0.9dB max. 2.0 max. 20dB min. at 2400~2500 MHz
2400~2500 2.0 max.
LTD-1608-
2G4S1-A3
Common Port
4900~5850
-
2.0 max.
-
C
Common to
Low Freq .Port
2400~2500 0.7 dB max. 2.0 max. 20 dB min. at 4800~6000 MHz
Common to
High Freq .Port
4900~5850 0.9 dB max. 2.0 max. 20 dB min. at 2400~2500 MHz
2400~2500 2.0 max.
LTD-1608-
2G4S1-A4
Common Port
4900~5850
-
2.0 max.
-
C
Common to
Low Freq .Port
2400~2500 0.6 dB max. 2.0 max.
20 dB min. at 4800~6000 MHz
20 dB min. at 7200~7500 MHz
Common to
High Freq .Port
5100~5900 1.4 dB max. 2.0 max.
35 dB min. at 2400~2500 MHz
18 dB min. at 3300~3900 MHz
12 dB min. at 9800~11900 MHz
2400~2500 2.0 max.
LTD-1608-
2G4S1-A7
Common Port
5100~5900
-
2.3 max.
-
A
Common to
Low Freq. Port
2400~2500 0.7 dB max. 2.0 max.
20 dB min. at 4800~6000 MHz
15 dB min. at 7200~7500 MHz
Common to
High Freq. Port
4900~5950 1.0 dB max. 2.0 max.
20 dB min. at 1800~2500 MHz
20 dB min. at 9800~11900 MHz
2400~2500 2.0 max.
LTD-2012-
2G4S1-D1
Common
Port
4900~5950
-
2.0 max.
-
A
Common to
Low Freq. Port
2400~2500 0.7 dB max. 2.0 max.
20 dB min. at 4800~6000 MHz
20 dB min. at 7200~7500 MHz
Common to
High Freq. Port
4900~5950 1.0 dB max. 2.0 max.
20 dB min. at 1800~2500 MHz
25 dB min. at 9800~11900 MHz
15 dB ref. at 14700~17850 MHz
2400~2500 2.0 max.
LTD-2012-
2G4S1-D2
Common
Port
4900~5950
-
2.0 max.
-
A
