RG-TDMOD 14
Drive Control & Communication
NOTE 1 - Drive Control
• During each write to Register #1 only one bit should be set in the drive control word.
• If more than 1 bit is set, the drive responds to stop bit only.
• If stop bit is not set, but more than 1 bit is set, drive responds with exception 04.
NOTE 2 - Drive Family
• The QC and DL Series drives return 64 (40H)
• The MC Series drives return 65 (41H)
• The SC Series drives return 66 (42H)
• The MCH Series drives return 68 (44H)
• The
smd Series drives return 69 (45H)
• The TC Series drives return 70 (46H)
• The
Tmd Series drives return 71 (47H)
• The SMV Series drives return 72 (48H)
5.3 Drive Size - Register #21
Table 9 lists the
Tmd Series drives. Register 21 will contain the value in the "Size" column.
Table 9: Drive Size - Register #21
Size
kW
Voltage
Size
kW
Voltage
00
0.55
1/N/PE or 3/PE
230V
28
0.55
3/PE
400/480V
01
0.37
29
0.37
02
0.75
30
0.75
03
1.1
31
1.1
04
1.5
32
1.5
05
2.2
33
2.2
16
0.75
3/PE
230V
34
4.0
17
1.1
35
5.5
18
1.5
36
7.5
19
2.2
44
3.0
20
4.0
21
5.5
22
7.5
