Before you start
The Mounting Instructions
EDKCSZS000 DE/EN/FR 4.1
10

DUMMY_NUM_Reset-ECSCS000_Liefer_BL
0Fig. 0Tab. 0 The Mounting Instructions
ƒ describe how to install the ECSZS000X0B shield connection,
ƒ contain the most important technical data of the ECSZS000X0B shield connection,
ƒ are only valid in conjunction with the Operating Instructions of the axis module
ECSxA or the supply module ECSxE.
Scope of supply
ecs070
Application of the shield connection
ECSxA ECSxE
 Shield sheet Motor cable Mains cable or cable of external brake
resistor
z If mains cables > 0.25 m and an
external brake resistor are used,
2 shield connections are required.
 Wire clamp for
shield connection
Motor cable Mains cable or cable of external brake
resistor
 Wire clamp for
shield connection
Control cable, system bus
cable
Control cable, system bus cable
 Wire clamp for
shield connection
Brake control –
