Page 33: Mechanical installation
Mechanical installation
Motor mounting
4
EDK82ZMBRB DE/EN/FR 1.0
33
l
H1_MechINS−E82ZMBRB_motmont_motec_EN
4
Mechanical installation
Motor mounting
Preliminary works
8200mot139
1. Dismount motor terminal box.
2. Dismount motor terminal board.
3. The motor connections must be approx. 15 cm long, if necessary, extend them.
