3 Technical data
General data/operating conditions
EDK82ZMBRB DE/EN/FR 1.0
30
l
H1_Daten−E82ZxBRB_Schalthaeufig_BFK06_08_DE
3 Technical data
General data/operating conditions
Function
The electronic brake switch enables the control of the electromechanical holding brake in
a brake motor.
Application range
The electronic brake switch can be used together with 8200 motec frequency inverters of
type E82MV251_2B or E82MV371_2B.
General data
Conformity and approval
Conformity
CE 73/23/EEC Low−Voltage Directive
Approval
UR UL 508C Industrial Control Equipment Recognised
(file no. E132659) for USA
Protection of persons and equipment
Enclosure EN 60529 IP00
Protective measures Against short circuit
EMC
Noise emission EN 61800−3 Conducted, category C2.
Noise immunity EN 61800−3 Burst on mains cable: 2 kV/5 kHz
Burst on control cable: 2 kV/5 kHz
Surge on mains cable: 1 kV (1.2
m
s/50
m
s;
phase − phase)
2 kV (1.2 m s/50 m s;
phase − PE)
