Page 92
Electrical installation
Motor connection
Fan connection
l
92
EDKVF9383 DE/EN/FR 4.0
Motor connection
0
1
BR2
BR2
BR1
BR1
PE
PE
U
U
V
V
W
W
40 mm
40 mm
PE
15-20 Nm
M6
133-176 lb-in
PE
15-20 Nm
M6
133-176 lb-in
U, V, W
25-30 Nm
M8
221-264 lb-in
U, V, W
25-30 Nm
M8
221-264 lb-in
2
2
3
3
max.
300 mm
max.
300 mm
9300VEC036
Fig. 5−12
Motor connection example
BR1, BR2
Brake resistor can only be operated with the variants V060, V110, V270 and V300
For connection see System Manual of 9300 vector
0
Master terminals
1
Slave terminals
2
Connect the motor cable shield with a surface as large as possible to the control
cabinet mounting plate by using the clamps.
3
Conductive surface
Ensure to have the poles right!
Do not exceed the maximum motor cable length!
Cable cross−sections for the motor connection
Type
Installation to EN 60204−1
U, V, W [mm
2
]
PE [mm
2
]
Master
Slave
Master
Slave
EVF9381−EV
EVF9381−EVxxxx
150
2 Ч 50
1)
150
2 Ч 50
1)
95
95
EVF9382−EV
EVF9382−EVxxxx
150
2 Ч 50
1)
150
2 Ч 50
1)
95
95
EVF9383−EV
EVF9383−EVxxxx
240
2 Ч 95
1)
240
2 Ч 95
1)
150
150
1)
Multiple conductor; both conductors must have the same cross−section
Observe the national and regional legislation
