Technical data
Rated data
Controller for a mains voltage of 400 V / 500 V
3
l
75 EDKVF9383 DE/EN/FR 4.0
3.3.2 Controller for a mains voltage of 400 V / 500 V
Rated data at a mains voltage of 400 V
Type Power Mains voltage Mains
current
Output current 1) Weight
iN I
max
(60 s)  ‚
EVF9381−EVV210
EVF9381−EVV240
EVF9381−EVV270
EVF9381−EVV300
250 kW
3/PE AC 400 V
340 V − 0 % ... 577 V + 0 %
45 Hz − 0 % ... 65 Hz + 0 %
alternatively:
DC 565 V
DC 480 V − 0 % ... 800 V + 0 %
475 A 500 A 750 A 320 kg 350 kg
EVF9382−EVV210
EVF9382−EVV240
EVF9382−EVV270
EVF9382−EVV300
315 kW 570 A 600 A 900 A 320 kg 350 kg
EVF9383−EVV210
EVF9383−EVV240
EVF9383−EVV270
EVF9383−EVV300
400 kW 713 A 750 A 1125 A 400 kg 430 kg
 Weight without RFI filter A
‚ Weight with integrated RFI filter A
1) At rated mains voltage and a switching frequency of 2 kHz
Rated data at a mains voltage of 500 V
Type Power Mains voltage Mains
current
Output current 1) Weight
iN I
max
(60 s)  ‚
EVF9381−EVV210
EVF9381−EVV240
EVF9381−EVV270
EVF9381−EVV300
315 kW
3/PE AC 500 V
340 V − 0 % ... 577 V + 0 %
45 Hz − 0 % ... 65 Hz + 0 %
alternatively:
DC 705 V
DC 480 V − 0 % ... 800 V + 0 %
475 A 500 A 750 A 320 kg 350 kg
EVF9382−EVV210
EVF9382−EVV240
EVF9382−EVV270
EVF9382−EVV300
400 kW 570 A 600 A 900 A 320 kg 350 kg
EVF9383−EVV210
EVF9383−EVV240
EVF9383−EVV270
EVF9383−EVV300
500 kW 713 A 750 A 1125 A 400 kg 430 kg
 Weight without RFI filter A
‚ Weight with integrated RFI filter A
1) At rated mains voltage and a switching frequency of 2 kHz
