Lenze EPM−H315 - Manual (Page 66)

Operation
Data input
6
l
66 EDBPM−H315 DE/EN/FR 7.1
Example Press keys ... If you want to ...
F change a digit.
1. Change to the parameter level (see
step D).
2. Select the desired digit. or
Feld 1 ON
Feld 2 -1 34
Feld 3 1A3F
9
3. Change the digit.
A B C
0
... + / -
9
4. Confirm the input.
– The cursor changes to the menu
level.
Enter
G enter a new hexadecimal value.
1. Change to the parameter level (see
step D).
2. Leave the cursor on the right digit.
Feld 1 ON
Feld 2 -1934
Feld 3 1A3 F
3. Enter the value of the first digit (e.g.
B").
– All other positions will be set to
zero.
– The digit entered will shift one
place to the left.
A B C
0
3x
Feld 1 ON
Feld 2 -1934
Feld 3 000 B
4. Enter the value of the next digit (e.g.
D").
– The digit entered will shift one
place to the left.
5. Repeat step 4. until the value is
complete.
A B C
0
2x
Feld 1 ON
Feld 2 -1934
Feld 3 00B D
6. Confirm the input.
– The cursor changes to the menu
level.
Enter
H change a hexadecimal digit.
1. Change to the parameter level (see
step D).
2. Select the desired digit. or
Feld 1 ON
Feld 2 -1934
Feld 3 1 3F C 3. Change the digit (e.g. C").
A B C
0
4x
4. Confirm the input.
– The cursor changes to the menu
level.
Enter
I change a dynamic text field.
1. Select the text. Help
á
or Info
â Feld 1 N
Feld 2 -9876
Feld 3 1A3F
O
2. Confirm the input.
– The cursor changes to the menu
level.
Enter
