Operation
Data input
6
l
65 EDBPM−H315 DE/EN/FR 7.1
6.2 Data input
Data input and data modification are described step−by−step using examples.
If you want to ... Press keys ... Example
A select a menu.
F6
F1
...
F10
F5
or
shift
+
F6
F1
...
F10
F5
B select a page. PgUp or PgDN
C place the cursor on the previous or next
field. or
Feld 1 ON
Feld 2 -987
Feld 3 1A3F
6
D activate the parameter level.
l The cursor is placed on the right digit.
l In dynamic text fields, the cursor is
placed on the left character (see step
I).
Enter
Feld 1 ON
Feld 2 -987
Feld 3 1A3F
6
E enter a completely new value.
1. Change to the parameter level (see
step D).
2. Leave the cursor on the right digit
3. Enter the value of the first digit.
– All other positions will be set to
zero.
– The digit entered will shift one
place to the left.
A B C
0
... + / -
9 Feld 1 ON
Feld 2 000
Feld 3 1A3F
1
4. Enter the value for the next digit.
– The digit entered will shift one
place to the left.
A B C
0
...
A B C
0 Feld 1 ON
Feld 2 001
Feld 3 1A3F
2
5. If necessary, insert a point.
TIP! Points can only be inserted if the
field is defined as Floating Point"
(see HMI Designer" planning tool).
6. Repeat step 4. until the value is
complete.
shift
+ ·
±space Feld 1 ON
Feld 2 012
Feld 3 1A3F
.
7. If necessary, enter a sign. ·
±space
Feld 1 ON
Feld 2 -12.3
Feld 3 1A3F
4
8. Confirm the input.
– The cursor changes to the menu
level.
Enter
