SimpleServo 100/200 User Manual Rev 3.4
WARNING!
Hazard of electrical shock! Circuit potentials are at 115 VAC or 230 VAC above earth
ground. Avoid direct contact with the printed circuit board or with circuit elements to
prevent the risk of serious injury or fatality. Disconnect incoming power and wait 60
seconds before servicing drive. Capacitors retain charge after power is removed.o
DO NOT connect incoming power to the output motor terminals (U, V, W)! Severe
damage to the SimpleServo will result.
DC+
DC-
SS108/208DC
80-170VDC
SS108/208AC
100-120VAC
TB1
1
2
3
4
5
TB1
1
2
3
A1.2 Incoming power connection
