SimpleServo 100/200 User Manual Rev 3.4
DS2 (Serial Communications Port input to Servo)
DS2 is a 9-pin DB connector that is used to communicate with a host computer. All levels must be RS-
232C compliant.
Table 6. TB505 Pin Assignments
"D"-Sub Pin # Name Function
1 Reserved
2 TX RS232 TX
3 RX RS232 RX
4 Reserved
5 GND Common
6 Reserved
7 Reserved
8 Reserved
9 Reserved
WARNING!
Do not make any connection to Reserved pins!
Note:
If you purchase serial cables from a third party, you must use pass-through cable, not
Null-Modem (not crossover).
17
