SimpleServo 100/200 User Manual Rev 3.4
DIMENSIONS AND WEIGHT
Model S108DC SS208DC SS108AC SS208AC
Height (inches) 7.35 7.35 7.35 7.35
Width (inches) 1.25 1.25 2.5 2.5
Depth (inches) 4.40 4.40 4.40 4.40
OPERATING MODES
Torque
Reference 0 ± 10 VDC or 0 to 10 VDC, scalable
Accuracy ± 0.01 amp
Current-Loop Bandwidth up to 2.5 kHz
Velocity
Reference 0 ± 10 VDC or 0 to 10 VDC
Accuracy ± 0.5 RPM
Velocity-Loop Bandwidth up to 300 Hz
Speed Range up to 8000:1
Position (SS208AC SS208DC only)
Reference Step and direction signals or Master Encoder full
quadrature signal (software selectable).
Minimum Pulse Width 250 nanoseconds
Reference Max frequency 2 MHz
Position-Loop Bandwidth Up to200 Hz
Accuracy ±1 encoder count
CONNECTIONS
Serial Standard 9-pin D-shell
Encoder Feedback Standard 15-pin D-shell
I/O 15-pin removable terminal block or 25-pin D-shell
Power in
SS108AC, SS208AC 3-pin AC socket
SS108DC, SS108DC 15-pin removable terminal block or 25-pin D-shell
Windows® Software: MotionViewTM (Windows 95, 98, NT)
7
