SimpleServo 100/200 User Manual Rev 3.4
Specifications
ELECTRICAL CHARACTERISTICS
Drive
Maximum
Continuous
Current (AC)
Continuous
Phase Current
(AC RMS)
Peak
Current
(AC RMS)
Input Voltage
SS108DC
-
8A
12A
80 - 170
SS208DC
-
8A
12A
80 - 170
SS108AC
5
8A
12A
60 - 120
SS208AC
5
8A
12A
60 - 120
Applies to all models:
AC Output Voltage Range (Sinusoidal, Three-Phase)
0 - 120 VAC RMS
Acceleration Time Range (Zero to Max Speed)
0.1 - 5000000 Rpm/sec
Deceleration Time Range (Max Speed to Zero)
0.1 - 5000000 Rpm/sec
Speed Regulation (typical)
± 0.5 RPM
Input Impedance (+REF to COM and +REF to -REF)
47 kohms
Power Device Switching Frequency (sinusoidal commutation)
16 kHz
Encoder power supply (max)
+5 VDC @ 300 mA
Maximum encoder feedback frequency
2.5 MHz
ENVIRONMENT
Vibration
0.1 G (all frequencies)
0.5G max (20 - 50 Hz)
0.1G max (>50 Hz)
Shock
1.0 g @10 m/sec
Ambient Operating Temperature Range
0 to 40ºC
Ambient Storage Temperature Range
-10 to 70ºC
Humidity
5 - 90% non-condensing
Altitude**
1500 m/5000 ft
**derate by 1% per 300m (1000 ft) above 1500m (5000 ft)
