Appendix A
SIMPLESERVO SYSTEM CONNECTION EXAMPLES
A1. SIMPLESERVO CONNECTIONS
PC COMPUTER
RS-232 INTERFACE
RS-232
ANALOG/DIGITAL I/O
Motor Feedback
Motor Power
BLDC
MOTOR
SS108
A-
Hall A-
B+
Hall A+
B-
Hall B+
Z+
Hall C+
Z-
Hall B-
Encoder COM
Hall C-
TX
RX
U
V
W
A+
+5VDC (Encoder Power)
TB2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
DS1
CONNECTOR DB15
8
15
7
14
6
13
5
12
4
11
3
10
2
9
1
DS2
CONNECTOR DB9
5
9
4
8
3
7
2
6
1
TB1
1
2
3
4
5
A1.1 Motor and Host computer connection
