SimpleServo 100/200 User Manual Rev 3.4
Operations
CONFIGURE THE SIMPLESERVO
Regardless of the mode in which you wish to operate, you must first configure the SimpleServo for your
particular motor, mode of operation and additional features if used.
1. Ensure that the control is properly installed and mounted. Refer to "INSTALLATION" section early in
this manual for installation instructions.
2. Perform wiring to the motor and external equipment suitable for desired operating mode and your
system requirements. Refer to system configurations diagram in Section A for various system
configuration examples.
3. Connect drive serial port DS2 to your PC serial port.
4. Turn power to the drive ON.
5. Make sure that the drive is disabled.
6. Launch MotionView software on your computer.
7. From the MotionView menu, select and select "RS-232" radio button on
opened connection dialog. Click and select the serial port number to which the drive is
connected. Leave the rest of the settings unchanged. Click to close dialogs.
8. From menu, click then .
9. Set parameters for the drive according to the section "Drive configuration procedure" in MotionView
Help file. (Select ; expand book; and select "Drive configuration
procedure").
10. After you configure the drive, proceed to tuning procedure if operating in Velocity or Step & Direction
mode. Torque Mode doesn't require additional tuning or calibration. Refer to MotionView Help file book
"Tuning" for instructions on how to tune for Velocity or Step & Direction mode.
21
