SimpleServo 100/200 User Manual Rev 3.4
CONNECTORS
AC power in (AC models only)
This power entry connector located on the bottom and made to accommodate standard 3-prong computer
AC cable plug.
WARNING!
DO NOT connect incoming power to the output motor terminals (U, V, W)!
Severe damage to the SimpleServo will result.
Note:
All conductors must be enclosed in one shield and jacket around them. The shield on
the amplifier end must be terminated at the case (chassis ground); the other end
should be properly terminated at the motor shield. To satisfy CE requirements, AC
Technology Corp recommends that you purchase SimpleServo cables for both the
motor and AC line. Contact your AC Technology Corp representative for assistance.
DC power in (DC models only)
DC power is connected via terminals 1 and 2 on TB1 connector. See description of TB1 functions below.
WARNING!
DO NOT connect incoming power to the output motor terminals (U, V, W)!
Severe damage to the SimpleServo will result.
TB1 - Power (DC units only), Motor and Fuse Connections
Table 3. TB1 Pin Assignments
Terminal Block Pin # Name FUNCTION
1 W (T) +DC in (DC models only)
2 V (S) -DC in (DC models only)
3 W (T) Motor Power Out
4 V (S) Motor Power Out
5 U (R) Motor Power Out
14
