Electrical installation
EDK82ZAFVC001 DE/EN/FR 2.0
42
l
M5 Kabelspezifikation−innenschaltung
Specification of the transmission cable
The devices are connected to the bus system using a fieldbus cable according to the
DeviceNet
TM
specification (DeviceNet Adaption of CIP, Edition 1.1, Volume Three).
Companies like Belden Wire & Cable, Olflex Wire & Cable, C&M Corp. and Madison Cable
produce DeviceNet
TM
Thick" and Thin" cables.
)
Note!
Use the Thin" cable to wire the function module
^ 42
.
Features of the Thin" cable according to DeviceNet specifications
General features
Configuration
Two shielded symmetrical cables with a common axis and drain wire in
the centre
Total shielding
65% coverage
AWG 36 or min. 0.12 mm tinned braid (individually tinned)
Drain wire
Copper 22 min.; min. 19 cores (individually tinned)
Outer diameter
6.096 mm (min.) to 7.112 mm (max.)
Roundness
Radius deviation must be within 20% of 0.5 outer diameter
Jacket marking
Vendor name & part no. and additional markings
Spec. DC resistor (braid, tape, drain)
10.5 Ohm/1000 m (nominal at 20°C)
Certifications (U.S. and Canada)
NEC (UL), CL2 (min.)
Bend radius
20 x diameter (installation) / 7 x diameter (fixed)
Ambient operating temperature
−20°C to +70°C at 1.5 Ampere; derate current linearly to zero at 80°C
Storage temperature
−40°C to +85°C
Pull tension
289.23 N
max
