4 Technical data
General data
EDK2191DB DE/EN/FR 2.0
28
l
H1_Daten−LESE_Dokus_8200_9300_ECS
4 Technical data
General data
Field Values
Order designation EMF2191IB
Communication profile Ethernet POWERLINK V2
Interface RJ45, Fast Ethernet Mode MII (according to IEEE 802.3)
Communication medium TP (100BaseTX, Cat5e)
Cable length max. 100 m between 2 nodes / hubs
Total extension Number of nodes x 100 m
Network topology Tree, star, line
Transmission mode Half duplex
Type of node Slave (CN, Controlled Node)
Node address Max. 239
Conformities, approvals l CE
l cUL
Baud rate 100 Mbps
Voltage supply External supply via separate power supply unit
+ V =
I =
24 V DC (20.4 V − 0 % ... 28.8 V + 0 %)
140 mA
− Reference potential for external voltage supply
,
Documentation for Lenze series of devices 8200 vector, 9300 and ECS
Here you can find the ambient conditions and the electromagnetic
compatibility (EMC) specifications applying to the communication module.
