3 Product description
Function
EDK2191DB DE/EN/FR 2.0
26
l
−H1−typbezeichnung
3 Product description
Function
The communication module connects the Lenze inverter to the Ethernet POWERLINK
communication system.
Application as directed
The communication module ...
ƒ is a device intended for use in industrial power systems;
ƒ can only be used in POWERLINK networks;
ƒ can be used together with the following standard devices (nameplate data):
Device type Design Version Variant Explanation
HW SW 1)
82EVxxxxxBxxxXX ³
Vx
³
1x 8200 vector
82CVxxxxxBxxxXX ³
Vx
³
1x 8200 vector, cold plate
82DVxxxKxBxxxXX ³
Vx
³
1x 8200 vector, thermally
separated
EPL 10200 E ³
1x
³
1x Drive PLC
33.93XX xE. ³ 2x ³ 1x Vxxx 9321 − 9332 vector
33.938X xE. ³
1x
³
0x 9381 − 9383 vector
33.93XX xC. ³
2x
³
1x Vxxx 9321 − 9332, with cold
plate version
33.93XX EI / ET ³ 2x ³ 1x Vxxx 9300 Servo PLC
33.93XX CI / CT ³
2x
³
1x Vxxx 9300 Servo PLC, cold plate
ECSxSxxxx4xxxxXX ³ 1A ³ 6.0 ECSxS "Speed & Torque"
ECSxPxxxx4xxxxXX ³
1A
³
6.0 ECSxP "Posi & Shaft"
ECSxMxxxx4xxxxXX ³
1A
³
6.0 ECSxM "Motion"
ECSxAxxxx4xxxxXX ³
1A
³
2.3 ECSxA "Application"
ECSxExxxx4xxxxXX ³
VA
³
3.0 ECSxE power supply
module
1) operating system software versions of the controllers
Any other use shall be deemed inappropriate!
