Parameter data transfer
Initialise PCP communication
Available PCP services
8
l
53 EDS82ZAFIC EN 2.0
Device version
Composition of the visible string:
ƒ Characters 1 ... 5: Software version of the controller:
– 2 characters of basic version
– 2 characters of variant
– 1 character of version of variant
ƒ Characters 6 ... 10: Software version of the function/communication module
– 2 characters of basic version
– 2 characters of variant
– 1 character of version of variant
ƒ Characters 11 ... 15: No name
– 5 spaces
Example:
8200 vector controller (version V3.7; without variant and variant version) with
communication module (version V2.0; without variant and variant version):
"3700020000 "
Visible string
Device version
Standard device
Device version
Module
Space
3 7 0 0 2 0 0 0 0 0
1 6 11 15
Status
The "Status" PCP service provides status information on the controller. The controller
provides the following values:
Status Value Meaning
Logical status 0 = ready for communication Information on the current operating mode (C0001) of
the controller regarding communication
Physical status l 0 = ready for operation
Operating status "OPERATION
ENABLED"
l 1 = partly ready for operation
all other device states
Information on the current operating status of the
controller.
(for device states, see
^ 42)
Local detail "Status word" parameter 24−bit value with:
l Bit 0 ... 15: "Status word" profile parameter (index =
0x6041)
l Bit 16 ... 23: Value 0
