Parameter data transfer
Configure parameter data channel (PCP communication)
Parameter sets for 8200 vector controller
l
48
EDS82ZAFIC EN 2.0
8.1.1
Parameter sets for 8200 vector controller
The 8200 vector controller has four parameter sets the parameters of which can be directly
addressed via the INTERBUS.
Addressing
Addressing is carried out with a code offset:
ƒ
Offset "0" addresses the parameter set 1 with the codes C0000 ... C1999.
ƒ
Offset "2000" addresses the parameter set 2 with the codes C2000 ... C3999.
ƒ
Offset "4000" addresses the parameter set 3 with the codes C4000 ... C5999.
ƒ
Offset "6000" addresses the parameter set 4 with the codes C6000 ... C7999.
If a parameter is only available once (see documentation of the controller), use the code
offset "0".
Example
Addressing of the code C0011 (maximum field frequency) in different parameter sets:
ƒ
C0011 in parameter set 1: Code no. = 11
ƒ
C0011 in parameter set 2: Code no. = 2011
ƒ
C0011 in parameter set 3: Code no. = 4011
ƒ
C0011 in parameter set 4: Code no. = 6011
)
Note!
Automatic saving of the changed parameter data is activated (Lenze basic
setting, can be switched off via C0003).
