Commissioning
Defining the user data length
l
30
EDS82ZAFIC EN 2.0
6.5
Defining the user data length
The number of process data words (PCD) and parameter data words (PCP) can be set via
code C1515 or via the DIP switches S2 ... S4.
)
Note!
ƒ
Sum of all data words (PZD + PCP): max. 4 words
ƒ
Switch off the voltage supply of the function module and the controller and
then on again to activate the changed settings.
Settings via DIP switches S2 ... S4
ON
OFF
1
ON
2 3 4
E82ZAFI009
ƒ
If one of the DIP switches S2 ... S4 is set to OFF, the configurations resulting from all
switch positions are active at switch−on.
ƒ
If the switch positions are invalid, the Lenze setting is activated:
– DIP switches S2 ... S4 = OFF (2 PCD words + 1 PCP word)
ƒ
Code C1525 displays the current settings of the DIP switches S2 ... S4.
DIP switch
Value
Number of process data
words (PCD)
Number of parameter
data words (PCP)
ID code
S2
S3
S4
OFF
OFF
OFF
0
2
1
227
ON
OFF
OFF
1
3
1
227
OFF
OFF
ON
4
2
0
3
ON
OFF
ON
5
4
0
3
ON
ON
ON
Code C1515 active.
