Electrical installation
EDK82ZAFIC−010 DE/EN/FR 6.0
46
l
H1_E_INST−Umgang_m_Steckerleisten
6
Electrical installation
(
Stop!
Observe the following to prevent any damage to plug connectors and
contacts:
ƒ
Only pug in / unplug the plug connectors when the controller is
disconnected from the mains.
ƒ
Wire the plug connectors before plugging them in.
ƒ
Unused plug connectors must also be plugged in.
Use of plug connectors with spring connection
E82ZAFX013
