4 Technical data
Operating conditions
EDK82ZAFIC−010 DE/EN/FR 6.0
42
l
−H2−Schutzisolierung
Operating conditions
Ambient conditions
Climate
Storage IEC/EN 60721−3−1 1K3 (−25 to +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 to +70 °C)
Operation Corresponding to the data of the Lenze standard device used (see
documentation of the standard device).
Pollution EN 61800−5−1 Degree of pollution 2
Degree of protection IP20 (protection against accidental contact according to NEMA 250 type 1)
Protective insulation
Insulation between incoming bus and ... Type of insulation (acc. to EN 61800−5−1)
l 8200 vector/motec power section Reinforced insulation
l Reference earth / PE Functional insulation
l Terminal X3.1/59 Functional insulation
l Terminal X3.3/20 Functional insulation
l Terminal X3.3/28 Functional insulation
Insulation between incoming bus and ... Type of insulation (acc. to EN 61800−5−1)
Outgoing bus Functional insulation
Insulation between outgoing bus and ... Type of insulation (acc. to EN 61800−5−1)
l 8200 vector/motec power section Reinforced insulation
l Reference earth / PE Functional insulation
l Terminal X3.1/59 No electrical isolation
l Terminal X3.3/20 No electrical isolation
l Terminal X3.3/28 Functional insulation
