Safety engineering
Device modules
Safety module SM100
1
l
18 EDS94AYAB EN 2.1
1.2.4.6 Test certificate
Zertifikat_el325
Fig. 1−4 TÜV Certificate
The type test was carried out by ’TÜV Rheinland Group’ and confirmed with a certificate.
Contents Specifications
Test institute TÜV Rheinland Industrie Service GmbH, ASI business area
Test report 968/EL 325.02/07
Test fundamentals EN ISO 13849−1, EN 60204−1, EN 50178, EN 61800−3, IEC 61508 Part 1−7,
EN 62061, IEC 61800−5−2
Object to be examined SM100, type E94AYAB of the Servo Drives 9400 series
Test result The module meets the requirements according to ISO 13849−1, category 4/PL
e and of SIL 3 according to IEC 61508.
Special conditions The safety instructions in the corresponding user documentation must be
observed.
Place of issue Cologne
Issue date 01.10.2007
