3 electrical installation – Lenze E94AYFLF User Manual
Page 18
3
Electrical installation
EDK94AYFLF DE/EN/FR/ES/IT 2.1
18
l
H1_E_INST−Belegung_SubD_X10
3
Electrical installation
(
Stop!
The output voltages on X9/4 and on X10/4 may not be interconnected. This
applies to both the wiring of several modules and to the wiring of one module
(e. g. for purposes of simulation).
Use system cables not connecting pin 4 for this applications only.
I
Tip!
We recommend the use of Lenze system cables. For this purpose, please read
the documentation for the basic device.
