2 Technical data
)
Note!
Only one module per basic device may be used, either in module receptacle
MXI1 or MXI2.
(
Stop!
The output voltages on X9/4 and on X10/4 may only be charged at a total of
max. 150 mA.
If the output voltage on X9/4 is used, no digital input signal may be applied to
X9/8. In this case, the cable serves as a sensor lead. In case of a connection
error, the components connected to X9 are damaged.
Functions on X9
ƒ Input for encoder signals with TTL level
ƒ Voltage supply +5 V for encoder
ƒ Sensor lead (sense) at regulated voltage supply (Lenze setting)
– max. control range of the voltage drop on the cable: 4 V (corresponds to 5 ... 9 V
output voltage on X9/4)
ƒ Digital input signal (only with regard to unused or external voltage supply)
Functions on X10
ƒ Output for encoder signals with TTL level, directly or simulated
ƒ Voltage supply +5 V
ƒ Digital output signal
